E10850 - Reed Switch & Magnet, Safety, Router Stop & Drill Stop

Used on TSM-21 for Safety buttons, Router Stop and Drill Stop. Used on TSM-35 for Safety buttons. Used on Line Boring machines as Bit cover safety switch Reed Switch and Magnet, set.

H12075 - Flat Belt (Grey) 1 x 20.75 For newer machines

Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the H12075 Flat Belt (Blue) 1 x 20.75 DG1 is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial environment. Keep one on hand for a...

1/8 NPT x 10-32 Bushing, Brass (P317)

1/8 NPT x 10-32 Bushing, Brass (P317)

P21224 - 3 Port Humphrey Solenoid for TSM-22 (See notes for TSM-21, and TSM-31/TSM-35.)

Humphrey 310, 3 Port Solenoid Specifically engineered for use with the Castle TSM-22, TSM-21 (after SN:61076), TSM-30 series(Clamp function ONLY) line of Pocket Hole Machines the P21224 3 Port Humphrey Solenoid is a spare part you need to have...

N70118-005 5 pack- Button Poly Foot Pad 1 x 1/8"

The clamp foot pad keeps material secured while the pocket is cut and drilled.   This is a 5 pack.

C00200 - TSM Hold Down Foot w/ Pad

P00117 - Router Feed Rate Valve (See notes for TSM-35)

Used on TSM-20, TSM-21, TSM-22, TSM-31, and the TSM-35 as the Router Feed Rate valve. Also used on the TSM-31 and the TSM-35 as the Drill Feed rate and Drill Delay valve. One in each position. SMC Flow Control AS2000-N01

P00018 - 1/8” NPT Brass Muffler/Breather (P00018)

This ⅛ NPT Brass Muffler/Breather will fit the exhaust port in all TSM-21, TSM-22, TSM-35 and TSM-31 3 way and 4 way solenoids. Technical specifications: Thread: 1/8” NPT Material: brass

P49410 - Parker / Humphrey 410 24V DC Solenoid, 4 port for TSM-35

P01957 - Sioux Air Drill

Sioux air drill for the Castle TSM-35 and TSM-31 Specifically engineered for use with the Castle TSM-35 and TSM-31 pocket hole machines, the P01957 - Sioux Air Drill is an essential component to have on hand. Engineered to hold up to heavy duty use of...

E03000 - TSM-31/TSM-35 Stop Switch

C30352 - TSM-35 Stop Switch Actuator Assembly Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the C30352 - TSM-35 Stop Switch Actuator Assembly is a spare part you need to have. Engineered to hold up to heavy duty use...

E00491 - Foot Pedal w/ 8' Cord - Line Master 491-SC36

C00012 - Castle Door Hinge Set w/ Screws (2 Male & 2 Female)



E35010 - TSM-35 "End of Cycle" Switch

Used on TSM-35 for end of cycle sensing on the Drill and Router drive cylinders. Replaces Sick RZT6-03ZUS-KWO end of cycle switch.   Mounting strap may be reused.  If strap needs replacement order pn: E35009 Specifically engineered for...

N70118 - Button Poly Foot Pad 1 x 1/8"

The clamp foot pad keeps material secured while the pocket is cut and drilled.

C00015 - Castle Door Handle Assembly

P35300 - TSM-35 Router Cylinder

H00141 - Bar Knob 1/4"-20

H00141 Bar Knob 1/4"-20 Specifically engineered for use with the Castle TSM-21 line of Pocket Hole Machines the H00141 Bar Knob 1/4"-20 is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial environment. Keep one on...

P00538 - Push-In Straight Fitting 1/8"M x 5/32"

Pnuematic push in fittings for TSM 35 and CSI-Next

H35013 - TSM-35 Nylon Wear Strip

Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the H35013 TSM-35 Nylon Wear Strip is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial environment. Keep one on hand for a quick...

P10320 - SQE 10-32 Clippard

Air Management for the TSM-21, TSM-35, TSM-30 and TSM-31. When you are in need of premier woodworking tools and supplies, turn to Castle, Inc. We pride ourselves on providing our customers with the absolute best and highest quality carpentry supplies...

G00234 - Bit Gauge Aluminum Bar 1/8" x 1 x 2-3/4"

G00234 - Bit Gauge Aluminum FBar 1/8" x 1 x 2-3/4" Specifically engineered for use with the Castle TSM-21 line of Pocket Hole Machines the G00234 Bit Gauge Aluminum FBar 1/8" x 1 x 2-3/4" is a spare part you need to have. Engineered to hold up to heavy...

P35125 - TSM-35 Drill Cylinder

P35250 - Humphrey 250A-3-10 Pilot Valve

E91024 - Sprecher & Schuh Contactor

Sprecher & Schuh CA8-09-10-24Z Contactor for Castle TSM-35 & TSM-31.  Use with TSM-31 Single Phase Sprecher & Schuh Overload (E94061) or TSM-35 230V 3ph Sprecher & Schuh Overload (E94060) or TSM-35 480V 3ph Sprecher &...

E07041 - Foot Pedals Microswitch

Replaces stock microswitch in all footpedals.  Omron Mfr #Z-15G-B7-K

E35424 - TSM-35 Solid State Control Board

Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the E35424 TSM-35 Solid State Control Board is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial environment. Keep one on hand for a...

P35018 - 1/8 OD 1/16 ID Urethane tubing, Yellow

Tubing to use in the Castle TSM-35 and TSM-31. This product is sold by the foot.For parts and accessories for the TSM-35 the TSM-31 and all of our pocket cutter machines, please check out our service parts selection. For more information about the Castle...

E21016 - 16 Pin Terminal Strip for EL-21 & EL-35 Control Board

Terminal strip for Castle electrical boards. For parts and accessories for the TSM-35, the TSM-31 and all of our pocket cutter machines, please check out our service parts selection. For more information about the Castle line of industrial and personal...

H11775 - Nylon Flat Belt (Green) 1 x 17.75 for older machines

For use in older TSM-35 machines.  (Unmodified machines with serial numbers 3000 to 54334)   Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the H11775 Nylon Flat Belt (Green) 1 x 17.75 is a spare part you...

D00710 - Tapered Black Plastic Door Hinge, Male Half

This door hinge is tapered at one end.

C00215 - Complete TSM Clamp Cylinder Assembly

Used on TSM-20, TSM-21, TSM-22, TSM-31, and TSM-35. Clamp cylinder assembly: complete with Air inlet fitting, Clamp Foot, Foot pad, Jamb Nut and Mounting Nut.

E35009 - TSM-35 "End of Cycle" Switch Mounting Strap

Used on TSM-35 to mount "End of Cycle" Sick switch pn:E35010 to Drill and Router drive cylinders. Sick BEF-KHZ-RT1-63 Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the E35009 - TSM-35 "End of Cycle"  Switch...

H78065 - TSM-31/35 Router Spindle Bearing

Spindle bearing for TSM-31 and TSM-35 router spindles. -2 are required for the older style router spindle for TSM-31 and TSM-35 machines that have the Porter Cable Chuck and Collet (serial numbers 68269 and below).   -Only 1 H78065 is...

P00215 - TSM Clamp Cylinder

Used on TSM-20, TSM-21, TSM-22, TSM-31, and TSM-35 Note: Clamp Foot sold separately

D50044 - Sioux 1/4" Collet

P35026 - Parker 02FA06A 1/4" Disposable In-Line Filter

When running an air system on your Castle TSM-35 pocket hole machine, it is critical to install quality components for air management. A 1/4" Disposable In-Line Filter ensures that the air system runs safely, it protects the machine as well as the...

F14219 - 1/4-20 x 2” Ribbed Neck Carriage Bolt - OBSOLETE

This has been replaced by F14234

C35002 - Clippard TSM-31/35 Filter/Regulator/Luber Assembly

USE P35075. Click here: SNS FRL This Clippard branded FRL will retro fit to all TSM-35 and TSM-31 machines. Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the C35002 TSM-35 Filter/Regulator/Luber Assembly is a spare...

E03041 - TSM-35 Start Switch

C30351 - TSM-35 Start Switch Actuator Assembly Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the C30351 - TSM-35 Start Switch Actuator Assembly is a spare part you need to have. Engineered to hold up to heavy duty...

E16224 - Secondary Fuse 2A for older TSM-35s

2amp secondary Fuse, was orginally used for TSM-35s with older transformers like the Hammond E55750 and Micron E35713. Keep one or two of these fuses handy for those times when the fuse blows. Make sure that you are not stranded in the middle of your...

3/8 x .062 Black Polyethylene Tubing per foot

3/8 x .062 Black Polyethylene Tubing, sold by the foot

E03340 - TSM-31/35 Safety Interlock Switch

Safety Interlock Switch IDEC HS5D-11ZRNM can be used in place of Siemens brand switches. Please confirm interlock brand before purchase. For parts and accessories for the TSM-35, the TSM-31 and all of our pocket cutter machines, please check out our...

1/8M x 1/4 PI Straight (P215)

1/8M x 1/4 PI Straight (P215)

C35005 - TSM-35 Drill Delay Valve Assembly

C35005 - TSM-35 Drill Delay Valve Assembly Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the C35005 TSM-35 Drill Delay Valve Assembly is a spare part you need to have. Engineered to hold up to heavy duty use of an...

N35313 - TSM-31/35 Router Spindle, old PC Style

Older style Router Spindle for TSM-31 and TSM-35 machines that have the Porter Cable Chuck and Collet (serial numbers 68269 and below).  This Router Spindle will NOT work with newer machines that have the new Bosch chuck and collet system...

E03322 - Security Switch Key, ABB LSA30

E03322 - Security Switch Key, ABB LSA30 Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the E03322 Security Switch Key, ABB LSA30 is a spare part you need to have. Engineered to hold up to heavy duty use of an...

F14458 - 1/4-20 x 1-1/4" Socket Head Cap Screw For Pocket Cutter Machine

This set screw is used to adjust left/right carriage position on the TSM-21 and TSM-35. It is also used as the threaded mounting post for the porter cable 7301 in the TSM-21. When you are in need of premier woodworking tools and supplies, turn to Castle,...

TSM-31/35 Secondary Fuse 3A

For TSM-31 230v single phase, TSM-35 230v 3 phase, and TSM-35 460v 3 phase machines

E03300 - ABB LS35 Security Interlock Switch

  Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the E03300 ABB LS35 Security Interlock Switch is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial environment. Keep one on...

C35101 - TSM-35 Safety Blade Assembly

C35101 - TSM-35 Safety Blade Assembly Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the C35101 TSM-35 Safety Blade Assembly is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial...

D00720 - Tapered Black Plastic Door Hinge, Female Half

This door hinge is tapered at one end.

D50055 - TSM-31/35 Router Chuck, old PC style

Older style Router Chuck for TSM-31 and TSM-35 machines that have the Porter Cable Chuck and Collet (serial numbers 68269 and below).  This Router Collet will NOT work with newer machines that have the new Bosch chuck and collet system...

N35352 - TSM-31/35 Spindle Housing, old PC style

Older style Spindle housing for TSM-31 and TSM-35 machines that have the Porter Cable Chuck and Collet (serial numbers 68269 and below).  This spindle housing will NOT work with newer machines that have the new Bosch chuck and collet system...

M00235 - Foot Switch Guard - Yellow

P14018 - 1/8 NPT x 1/4 Push In Swivel Elbow

F11412 - 1-1/4-12 Jam Nut, Zinc Plated

Used to hold the clamp cylinder in place.

N35353 - TSM-35 Small Pulley

Specifically engineered for use with the Castle line of Pocket Hole Machines the N35353 TSM-35 Small Pulley is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial environment. Keep one on hand for a quick change in...

TSM-31/35 Router Spindle Assembly, New Bosch style with Bosch Wrenches

New Bosch Style TSM-31/TSM-35 Router Spindle Assembly.  This is our latest spindle with a Bosch chuck and collet.     Note: The old Porter Cable style spindle assembly is NO longer available. Machines with serial numbers...

C35021 - TSM-35 Router Drive Cylinder Assembly

Drop in replacement for the TSM-35 or TSM-31 router cylinder. Comes complete with clevis, air fittings and bumper. For parts and accessories for the TSM-35 the TSM-31 and all of our pocket cutter machines, please check out our service parts selection...

D50012 - 1/2" Collet Assy for Porter Cable #6902

1/2" collet assembly for the Porter Cable 6902 router.  Note: If using our standard 3/8" diameter router bits, you will need Part, N00538 - 1/2" to 3/8" Collet Reducer

T30466 - # 30466 11/16 Wrench for a Sioux 1954HPHT

# 30466 11/16 Wrench for a Sioux 1954HPHT

O15858 - TSM-31/35 Router Cylinder Bumper

O15858 - TSM-31/35 Router Cylinder Bumper Rubber bumper for the router cylinder for the Castle TSM-35 and TSM-31.  If you need to order a new router cylinder, this bumper is included with part C35021 - TSM-35 Router Drive Cylinder Assembly

C35022 - TSM-35 Drill Cylinder Assembly

Complete drill cylinder assembly for the Castle TSM-35 and TSM-31. Comes complete, ready to install.

M35017 - TSM-35 Drill Motor Plate

Sioux Drill Motor Mounting Plate.

P35081 - Clippard TSM-31/35 Lubricator

Clippard Lubricator for Castle TSM-35 and TSM-31.  Use with Clippard Filter/Regulator Castle part P35080. For parts and accessories for the TSM-35 the TSM-31 and all of our pocket cutter machines, please check out our service parts selection. For...

C00010 - Castle Front Door Assembly

Includes the following: CP0010 Front Door with Female Hinges  x1 D00710 Black plastic door hinge, male half (D1405) x2  G00101 Door Spring Clip Assembly x1  H00141 1/4-20 Bar Knob (H700)  x1 F14125 1/4-20 x 1/2 screw (F750) x1 F10010...

1/4 NPT x 3/8 PI Elbow - Legris (P233)

1/4 NPT x 3/8 PI Elbow - Legris (P233)

1/4-20 x 1-1/2 U-Bolt TSM-31/35 (F523)

1/4-20 x 1-1/2 U-Bolt for mounting TSM-31/35 router spindle, QTY 2 required (F523).

P01814 - Legris 1/8” NPT Female x 1/4” Straight Push-To-Connect Fitting (P01814)

Legris 1/8” NPT Female x 1/4” Straight Push-To-Connect Fitting is used on the TSM-35 to connect the air pressure switch to the airline. Push-in fittings allow fast circuit assembly for conveying compressed air, gas or liquids at a wide range...

P35066 - Parker TSM-31/35 Filter/Regulator

When running an air system on your Castle TSM-35 pocket hole machine, it is critical to install quality components for air management. A Parker lubrication and filter system ensures that the air system runs safely, it protects the machine as well as the...

SNS TSM-31/35 Filter/Regulator/Lubricator

SNS 1/4" NPT Compressed Air Filter Regulator Lubricator, Semi-auto Drain, Gauge and Bracket, Poly Bowl with Metal Guard  This SNS branded FRL will retro fit to all TSM-35 and TSM-31 machines.  Please note, this FRL has a 1/8" npt port that goes...

1/4 NPT Red Plastic Plug (P2900)

1/4 NPT Red Plastic Plug (P2900)

H00058 - Bushing QT 5/8"

Specifically engineered for use with the Castle TSM-35 line of Pocket Hole Machines the H00058 - Bushing QT 5/8" is a spare part you need to have. Engineered to hold up to heavy duty use of an industrial environment. Keep one on hand for a quick change...

TSM-31/35 Safety Interlock Key (E260) IDEC

TSM-35/TSM-31 Safety Interlock Key (E260) IDEC HS9Z-A52A for IDEC Interlock Switches IDEC HS5D-11ZRNM

D10140 - Sioux Collet Nut 1/4"

P35067 - Parker TSM-31/35 Lubricator

When running an air system on your Castle TSM-35 pocket hole machine, it is critical to install quality components for air management. A Parker lubrication system ensures that the air system runs safely, it protects the machine as well as the components...

C35001 - TSM-35 Rapid Index Assembly

Rapid Index Assembly for models TSM-31 and TSM-35 only.  Will not work with any other Castle machine model.

P35389 - TSM-35 3/8" Drill Hose Assembly

When running an air system on your Castle TSM-35 pocket hole machine, it is critical to install quality components for air management. The ⅜” drill hose ensures that the air system runs safely. Ideal for vacuum systems, blowers, and more!...

Scratch and Dent, Castle Front Door Assembly for TSM Series

Front Door Assembly, Complete with Hinges & Door Knob Includes the following: D00710 Black plastic door hinge, male half (D1405) x2  F10010 #12X1/2 Self Tapping SMS (F1058) x4  G00101 Door Spring Clip Assembly x1 H00141 1/4-20 Bar...

E35715 TSM-31/TSM-35, transformer, .50 KVA



E94061 - TSM-31 220v Single Phase Overload - Sprecher & Schuh

Sprecher & Schuh CT8-C10 Single Phase Overload.  Use this overload with Sprecher & Schuh Contactor (E91024)

M35011 - TSM-35 Flywheel

TSM-35 Flywheel.  This part is located on the Router Spindle Assembly. Made to hold up to the the heavy duty use that the TSM-35 Pocket Hole Machine is designed for. Keep one on hand for quick change in order to keep production steady. Please...

T30465 - # 30465 9/16 Wrench for Sioux 1954HPHT

# 30465 9/16 Wrench for Sioux 1954HPHT

TSM Hex Brass Pivot Bushing (M412)

TSM Hex Brass Pivot Bushing for carriage pivot points on the TSM-22, TSM-31, and TSM-35 machines.

Bosch 1617 Collet Wrench Set (Black)

Bosch 1617/1617EVS Collet Wrench Set

E35001 - Telemecanique Interlock Switch

TSM-35 interlock switch - used on older machines.  Please confirm interlock brand before purchase.

C35115 - TSM-35 Motor Pulley Assembly

Pulley assembly for the Baldor or Leeson motor on the TSM-30 series machine.

D35001 - Bosch 1/2" Collet Assembly

D35001 - Bosch 1/2" Collet Assembly for Bosch 1617 and 1617EVS routers.   Note: you will need a collet reducer for our 3/8" shank router bits, part number N00538 - 1/2" to 3/8" Collet Reducer

P35070 - TSM-35 Gauge

When running an air system on your Castle TSM-35 pocket hole machine, it is critical to install quality components for air management. A gauge ensures that the air system runs safely, it protects the machine as well as the components attached to the air...

1/4Male x 1/4 PI Straight Norgren (P225)

1/4Male x 1/4 PI Straight Norgren (P225)

10-32 X 5/8 Button Head Cap Screw S.S. (F833)

10-32 X 5/8 Button Head Cap Screw S.S. (F833)

16-4 SJ Motor Cord

16-4 SJ Motor Cord   Product is sold by the foot. Please add multiple qty for appropriate cord length.

3/8 Romex Connector w/ Nut (D1300)

3/8 Romex Connector w/ Nut (D1300)

5/8 ID Clear Rubber Bumper

5/8 ID Clear Rubber Bumper

E35131 - VL3513 - TSM-31 Baldor 1.5 HP Single Phase Motor

Baldor 1.5 HP Single Phase Motor for TSM-31,  Use motor slinger H00250.   Note: not for TSM-35 models.

F14234 - 1/4-20 x 1-3/4 Carriage Bolt (F106)

1/4-20 x 1-3/4 Carriage Bolt (F106) - Replaces F14219 1/4-20 x 2” Ribbed Neck Carriage Bolt

Humphrey Rod Clevis (D418)

original part number d07130

P35068 - Parker TSM-31/35 FRL Mount Bracket PS955P

P35069 - Parker TSM-31/35 FRL Connector
